Continuous Diamond Saw Blade (Wet-cutting)
|
Détails sur le produit:
Conditions de paiement et expédition:
|
Description de produit détaillée
Continuous Diamond Saw Blade (Wet-cutting)
Features: Rim type is ideal that water supply is adequate.Water plays two parts-cooling and removing cuts,which improves the use life
and cutting speed.The disc results in smooth and very clean cutting edge.
| Outer Diameter | Arbor Hole |
Segement Dimension (TxH) |
||
| Item No | Inches | Metric(mm) | (mm) | |
| SM-D012 | 4" | 105 | 16/20/22.23 | 1.8x5.0 |
| SM-D013 | 4.3" | 110 | 16/20/22.23 | 1.9x5.0 |
| SM-D014 | 4.5" | 115 | 20/22.23 | 1.9x5.0 |
| SM-D015 | 5" | 125 | 20/22.23 | 1.9x5.0 |
| SM-D016 | 6" | 150 | 20/22.23 | 1.9x5.0 |
| SM-D017 | 7" | 180 | 22.23/25.4/30 | 2.2x5.0 |
| SM-D018 | 8" | 200 | 22.23/25.4/30/50 | 2.4x5.0 |
| SM-D019 | 9" | 230 | 22.23/25.4/30/50 | 2.4x5.0 |
| SM-D020 | 10" | 250 | 22.23/25.4/30/50 | 3.0x5.0 |
| SM-D021 | 12" | 300 | 22.23/25.4/30/50 | 3.2x6.0 |
| SM-D022 | 14" | 350 | 22.23/25.4/30/50 | 3.2x6.5 |
1) Body material: 65Mn
Segment material: Diamond
2)Craft: sintered; brazed welded; laser welded
3)Application: Wet Cutting, ideal for cutting pavers, block, brick and concrete
